Why Self-Service Kiosks Need Reliable Receipt Printing

Self-service kiosks are becoming the standard in restaurants, cafes, retail, and automated checkout systems. A key part of that experience is the printing of receipts from order summaries to cardholder copies. In this guide, we break down how to implement thermal printer receipt printing using Node.js, ESC/POS commands, and network printing.

Why Kiosks Need Reliable Receipt Printing

Whether you’re operating a restaurant kiosk or a self-checkout terminal, receipts serve several important roles:

Customer validation (order number, items, payment confirmation)
Kitchen and staff workflow
Proof of payment (especially for card transactions)
Branding and professionalism

Network thermal printers are the preferred solution because they are:

Fast

Low maintenance

Silent

Support ESC/POS formatting

How Kiosk Receipt Printing Works

Your Node.js server sends a formatted ESC/POS text buffer to the printer using a TCP connection on port 9100.

Print flow:

Build receipt text
Apply ESC/POS formatting commands
Encode using the correct code page
Send buffer to the printer via the socket

1. Receipt Builder Code (buildCombinedReceipt)

Below is your complete, production-grade receipt builder.

Centered headings

Column formatting

Qty/Item/Price layout

Customizations

Euro symbol

Automatic cutting

Store header & footer

Payment details (cardholder copy)


 const iconv = require('iconv-lite');

 const net = require("net");

 const RECEIPT_WIDTH = process.env.RECEIPT_WIDTH ?  parseInt(process.env.RECEIPT_WIDTH) : 48;

 const EURO = '€';



 function getTextLength(text) {

  return text

   .replace(/[^\x00-\x7F]/g, "  ")

   .replace(/€/g, " ")

   .length;

 }



 function formatPrice(amount, width) {

 const safeAmount = typeof amount === "string" ? parseFloat(amount) : amount;

 if (isNaN(safeAmount)) throw new Error("Invalid amount for formatting");

 const withEuro = `${EURO}${safeAmount.toFixed(2)}`;

 return withEuro.padStart(width);

 }

function centerText(text, width = RECEIPT_WIDTH) {

 const textLength = getTextLength(text);

 if (textLength >= width) return text;

 const space = Math.floor((width - textLength) / 2);

 return " ".repeat(space) + text;

}

function padText(left, right, width = RECEIPT_WIDTH) {

 const leftLen = getTextLength(left);

 const rightLen = getTextLength(right);

 const spacing = width - leftLen - rightLen;

 return left + " ".repeat(Math.max(spacing, 0)) + right;

}

function getColumnWidths(width = RECEIPT_WIDTH) {

 const qtyWidth = 4;

 const priceWidth = 10;

 const itemWidth = Math.max(width - qtyWidth - priceWidth, 10);

 return { qtyWidth, itemWidth, priceWidth };

 }

 function buildHeader(width = RECEIPT_WIDTH) {

 const { qtyWidth, itemWidth, priceWidth } = getColumnWidths(width);

 const qtyStr = "QTY".padEnd(qtyWidth);

 const itemStr = "ITEM".padEnd(itemWidth);

 const priceStr = "PRICE".padEnd(priceWidth);

 return `${qtyStr}${itemStr}${priceStr}`;

 }

 function padColumns(qty, item, price, width = RECEIPT_WIDTH) {

 const { qtyWidth, itemWidth, priceWidth } = getColumnWidths(width);

 const qtyStr = qty.toString().padEnd(qtyWidth);

 let itemStr = item;

 if (getTextLength(itemStr) > itemWidth) {

   while (getTextLength(itemStr + "…") > itemWidth) {

     itemStr = itemStr.slice(0, -1);

   }

   itemStr += "…";

 }

 itemStr = itemStr.padEnd(itemWidth);

 const priceStr = formatPrice(price, priceWidth);

 return `${qtyStr}${itemStr}${priceStr}`;

 }

 function safeToFixed(value, digits = 2) {

  if (value === null || value === undefined) return "0.00";

 const num = typeof value === "string" ? parseFloat(value) : value;

 if (isNaN(num)) return "0.00";

 return num.toFixed(digits);

 }

function buildCombinedReceipt(order) {

 const { payment = {}, store = {} } = order;

 const lines = [];

 const ESC = '\x1B';

 const GS = '\x1D';

 const safeTotal = safeToFixed(order.total);

 const safeAmount = safeToFixed(payment.amount);

 lines.push("=".repeat(RECEIPT_WIDTH));

 lines.push(`${ESC}a\x01`);

 lines.push(`${GS}!` + '\x11');

 lines.push("Your order number is");

 lines.push(`${order.orderNo}`);

 lines.push(`${GS}!` + '\x00');

 lines.push(`${ESC}a\x00`);

 lines.push(centerText(order.eatingLocation || "N/A"));

 lines.push("=".repeat(RECEIPT_WIDTH));

 const rawHeaderLines = [

   store.name || "",

   store.contact_person || "",

   store.address || "",

   `Tel: ${store.phone || ""}`

 ];



 rawHeaderLines.forEach(rawLine => {

   const txt = rawLine.trim();

   if (!txt) return;

   const splitLines = txt.split(/\r?\n/);

   splitLines.forEach(line => {

     const cleanLine = line.trim();

     if (!cleanLine) return;

     const len = cleanLine.replace(/€/g, " ").length;

     const leftPad = Math.floor((RECEIPT_WIDTH - len) / 2);

     lines.push(" ".repeat(leftPad) + cleanLine);

   });

 });

 lines.push("-".repeat(RECEIPT_WIDTH));

 lines.push(centerText(order.date || ""));

 lines.push("-".repeat(RECEIPT_WIDTH));

 lines.push(buildHeader());

 lines.push("-".repeat(RECEIPT_WIDTH));

 (order.items || []).forEach((item, index) => {

   const qtyStr = (item.qty || 0).toString();

   const name = item.name || `Product ${item.Product_id || ""}`;

   const priceStr = safeToFixed(item.Retail_Price);

   lines.push(padColumns(qtyStr, name, priceStr));

   if (item.customizations?.length) {

     const display = item.customizations.filter(c => {

       const preSel = c.pivot?.input_type === "checkbox" && c.pivot?.pre_selected == 1;

       return preSel? c.removed === true: true;

     });

     const grouped = {};

     display.forEach(c => {

       const label =

         c.pivot?.product_groups_name ||

         c.label ||

         c.pivot?.label ||

         "Other";

       grouped[label] = grouped[label] || [];

       grouped[label].push(c);

     });

     const { qtyWidth } = getColumnWidths();

     const indentGroup = " ".repeat(qtyWidth);

     const indentItem = " ".repeat(qtyWidth + 3);



     Object.entries(grouped).forEach(([label, items]) => {

       lines.push(indentGroup + `${label}:`);



       items.forEach(c => {

         const qty = c.qty || c.quantity || 1;

         const qtyText = qty > 1 ? `${qty} x ` : "";

         const price = parseFloat(c.price ?? c.pivot?.price ?? 0);

         const total = safeToFixed(price * qty);

         const name = c.name || c.ItemName || "";

         if (label === "Remove") {

           lines.push(indentItem + `${qtyText}No ${name}`);

           return;

         }

         if (price === 0) {

           const free = c.free === true ? " (FREE)": "";

           lines.push(indentItem + `${qtyText}${name}${free}`);

           return;

         }

         lines.push(indentItem + `${qtyText}${name}: ${EURO}${total}`);

       });

     });

   }



   if (index < (order.items?.length || 0) - 1) {

     lines.push("");

   }

 });

 lines.push("-".repeat(RECEIPT_WIDTH));

 lines.push(padText("TOTAL (incl. VAT):", `${EURO}${safeTotal}`));

 lines.push("-".repeat(RECEIPT_WIDTH));

 lines.push(`${ESC}a\x01`);

 lines.push(`${GS}!` + '\x11');

 lines.push("CARDHOLDER COPY");

 lines.push(`${GS}!` + '\x00');

 lines.push(`${ESC}a\x00`);

 lines.push("-".repeat(RECEIPT_WIDTH));

 lines.push(`Transaction ID : ${payment.transactionId || ""}`);

 lines.push(`Auth No        : ${payment.authCode || ""}`);

 lines.push(`Card Type      : ${payment.cardType || ""}`);

 lines.push(`Card Number    : ****${payment.cardLast4 || ""}`);

 lines.push(`Amount Paid    : ${EURO}${safeAmount}`);

 lines.push("-".repeat(RECEIPT_WIDTH));

 if (store.footer_text) {

   store.footer_text.split(/\r?\n/).forEach(l => {

     if (l.trim()) lines.push(centerText(l.trim()));

   });

 }

 lines.push("\n\n\n");

 const receiptText = lines.join("\r\n");

 const cutCommand = Buffer.from([0x1D, 0x56, 0x00]);

 const initCodePage = Buffer.from([0x1B, 0x74, 0x13]);

 const encoded = iconv.encode(receiptText, "cp858");

 return Buffer.concat([initCodePage, encoded, cutCommand]);

}

module.exports = { buildCombinedReceipt };

2. Network Printing Code (sendToNetworkPrinter)


function sendToNetworkPrinter(buffer, printerInfo) {

 return new Promise((resolve, reject) => {

   const client = new net.Socket();

   const ip = printerInfo.ip || printerInfo;

   const port = printerInfo.port || 9100;

   client.connect(port, ip, () => {

     console.log(`✅ Connected to printer at ${ip}:${port}`);

     client.write(buffer);

     client.end();

     resolve();

   });

   client.on("error", (err) => {

     console.error("❌ Printer connection error:", err.message);

     reject(err);

   });

   client.on("close", () => {

     console.log("🔌 Connection to printer closed.");

   });

 });

}

module.exports = { sendToNetworkPrinter };

3. Print API Route


 const express = require('express');

 const router = express.Router();

 const { buildCombinedReceipt, sendToNetworkPrinter } = require('../utils/print-receipt-utils');



 router.post('/combined-receipt', async (req, res) => {

  try {

    const { orderNo, date, items, total, tax, eatingLocation, payment, printer, store } = req.body;

   console.log("items", items);



    if (!items || !payment || !store) return res.status(400).json({ error: "Missing order, payment info or store info" });



    const order = { orderNo, date, items, total, tax, eatingLocation, payment, store };



   const buffer = buildCombinedReceipt(order);

   await sendToNetworkPrinter(buffer, printer);



   res.json({ success: true, orderDetails: order, message: "Combined receipt printed" });

  } catch (err) {

   res.status(500).json({ error: "Failed to print receipt", details: err.message });

  }

 });

 module.exports = router;

Print Professional Receipts Directly from Your Kiosk

The Way Forward

With this Node.js-based receipt printing system, your kiosk can generate a complete, professional, and fully formatted receipt for every order. The solution supports printing all essential order details, including items, quantities, prices, and applied modifications, ensuring customers receive an accurate breakdown of their purchase. It also prints payment information, cardholder copies, store address details, and optional footer text when provided through the API.

The receipt layout includes the order number, eating location (such as dine-in or takeaway), and clear column alignment for easy readability. Unlike traditional POS systems, this setup prints directly through your own server and thermal printer without relying on a JCC terminal for receipt output. To enhance reliability, you can also track printer status and errors in Node.js to avoid failed print attempts and ensure smooth kiosk operations.

Overall, this system delivers a reliable, flexible, and kiosk-friendly printing experience that enhances customer satisfaction and ensures staff receive clear order documentation.
